ASTM B865 UNS N05500 Monel K500 Rod

Time: 2017-8-29   【Print】  【Close

Product Description:


ASTM B865 UNS N05500 Monel K500 Rod

monel k500 rod
1.Diameter:5mm-300mm
2.Standard:ASTM B160
3.Material:monel k500
4.High strength



monel k500 rod

1.Monel 500 Chemical composition


Alloy

%

Ni

Cu

Fe

C

Mn

Si

S

Monel500

Min.

63

28











Max.



34

2.5

0.3

2

0.5

0.024


2.Monel 500 Physical properties


Density

8.83 g/cm³

Melting point

1300-1390 °C


3.Monel 500 Alloy minimum mechanical properties in the room temperature


Alloy state

Tensile strength
Rm N/mm²

Yield strength
R P0. 2 N/mm²

Elongation
A 5 %

Monel500

480

170

35

Characteristic as below
Monel 500 is an extremely combination property that use for largest amount and most widely corrosion resistance alloy. This alloy in the hydrofluoric acid and fluoride gas medium with excellent corrosion resistance, as well as to the hot concentrated alkali. At the same time, is also corrosion resistant to neutral solution, sea water, air, organic compounds. An important feature of this is generally do not generate a stress corrosion cracking, good cutting performance.
Monel 500 Metallurgical structure
Monel 500 alloy is high-intensity single-phase solid solution.

Monel 500 Corrosion resistance
Monel 500 alloy in the fluoride gas, hydrochloric acid, sulfuric acid, hydrofluoric acid and their derivatives have a very good corrosion resistance property, and possess better corrosion resistance more than the copper alloy in the sea water. Acid medium: Monel500 have corrosion resistance in less than 85% consistency of sulfuric acid. Monel 500 is an important material that resistant to hydrofluoric acid. Water corrosion: Monel500 alloy in most corrosion cases of water, not only excellent corrosion resistance, but also less pitting, stress corrosion, the corrosion rate less than 0.025mm / a. High temperature corrosion: Monel 500 for the work of the highest temperature at about 600 °C in general in the air, in the high temperature steam, the corrosion rate less than 0.026mm / a. Ammonia: Monel 400 can be resistant to an hydrous ammonia and aminate conditions corrosion below 585 °C due to the high nickel.
4.Monel 500 Application field
Monel 500 alloy is a multi-purpose material in many industrial applications:
1. Seamless water pipe in the power factory
2. Sea-water exchanger and evaporator
3. Sulfuric acid and hydrochloric acid environment
4. Crude distillation
5. Sea-water in the use of equipment and propeller shaft
6. Nuclear industry and used in the manufacture of uranium enrichment isotope separation equipment
7. Manufacturing hydrochloric acid equipment used in the production of pump and valve
